Plates & Accessories

LAVINA Transport Wheel

A transport (3rd) wheel can be easily added to all 25/30/31″ S7 grinders and 25/30″ Elite grinders – part #L30GE02.10.00-1.

The transport wheel is included with all remote-controlled grinders (S7, Elite and older RC models).

LAVINA FOAM PLATES

Back by popular demand! Lavina foam plates feature flexible foam and heavy-duty velcro to attach your favorite velcro-backed tooling.

Offered in 9″ and 13″ to use with Lavina Grinders and Trowels. Compatible with S7, Elite and older models.

#LV9FPE – Lavina Foam Plate, 9 inch

#LV13FPE – Lavina Foam Plate, 13 inch

LAVINA SECURITY PLATES

We recommend using tool security plates to lock all QC tooling in place. Specify grinder model, heads diameter, and if it is QC or Ring security plate before ordering.

Pictured from left:
#A63.00.01 – QC security plate for 9″ S7 and Elite heads
#A64.00.01 – QC security plate for 13″ S7 and Elite heads
#A38.00.01 – QC security plate for 9″ X heads
#A38.00.02 – QC security plate for 13″ X heads
#A85.00.00 – Ring security for 9″ heads
#A84.00.00 – Ring security for 13″ heads

ADAPTER PLATES FOR QUICK CHANGE TOOLS

With Superabrasive’s adapter plates, you can easily switch to our Quick Change style tooling, no matter what grinder you have. We offer plates for HTC, Sase, Husqvarna, Edco, Diamatic, STI / PrepMaster, Klindex, Terrco, and other floor grinders, as well as a universal bolt-on tool adapters.

#XP-HTC-9 – QC Plate for HTC500 & HTC650

#XP-HTC-10.63 – QC Plate for HTC800, HTC950, SASE6000 & 8000

#XP-HUSQ-9 -QC Plate for Husqvarna PG530 & PG680

#XP-HUSQ-10.63 – QC Plate for Husqvarna PG820

#XP-SCANMASKIN-8.4 – QC Plate for Scanmaskin 650

#XP-SCANMASKIN-9.5-NEW – QC Plate for Scanmaskin 700/800/1000, after mid 2016

#XP-SCANMASKIN-9.5-OLD – QC Plate for Scanmaskin 700/800/1000, before mid 2016

#XP-7-EDCO – QC Plate for Edco, 7 inch

#XP-10-EDCO – QC Plate for Edco, 10 inch

BOLT-ON QC ADAPTERS

These universal adapters feature three standard threaded holes for easy bolting and our standard magnetic and dovetail security – just bolt on to your machine heads and start using Lavina QuickChange tools.

Pictured from left:

#XQC-HOLDER  – universal bolt-on adapter

#QC-HOLDER-EDCO – bolt-on adapter for Edco

#X-HOLDER-TER – bolt-on adapter for Terrco

#X-HOLDER-STI – bolt-on adapter for STI

VELCRO PROTECTORS

Velcro Protectors work great with foam plates and extend their life. Offered in 9″ and 13″ with cutouts for 3″ pucks.

#VP-9 – 9″ Velcro Protector with 3 x 83mm Cut outs

#VP-13.5 – 13.5″ Velcro Protector with 6 x 83mm Cut outs

QC HOLDERS FOR MAINTENANCE PADS

Designed to attach floor maintenance pads, such as SupraShine, directly to your Lavina grinder heads or Trowel Shine heads.

For 9″ heads use 3 pcs of #XQCPH9, and for 13″ heads use #A87.00.00R.

LIPPAGE HOLDERS AND BACKER PADS

Aluminum Lippage Holders are used for attaching vecro-backed tools and are offered in 4in and 83mm sizes. They are offered with a QuickChange attachment – #XQC-4LH, #XQC-83LH, and with a regular bolt-on attachment – #4LH, #83LH.

Rubbber spacers with Hook & Loop serve as a cushion between the diamond pad and the backer, and are offered in different diameters from 3″ to 9″.

We also offer rigid / aluminum and flexible backer pads for angle grinders. The rigid backers are used for straight edges and flat surfaces, and the flexible backers with foam are used for curved edges.

Weights for LAVINA Floor Grinders

Adding weights on the grinder head increases the grinding pressure and helps you to cut more aggressively. The new S7 floor grinders have integrated weights, but the L31 models can also take an additional (optional) weight – #A114.00.00 (75 lbs / 34 kg).
From the Elite models, only L16E uses horseshoe-style weights – you can add up to two 18.5 lbs / 8.5 kg weights – #L21-50.00.00.

The older LAVINA X, S, Pro, SPS grinders all use horseshoe style weights, offered in two sizes:

#A07.00.00.00 – 48 lbs weight for L20, 20N X, S, Pro, SPS
#A08.00.00.00 – 64 lbs weight for L25 and up X, S, Pro, SPS.

LAVINA Tool Box

The LAVINA tool box is ideal for storing and carrying your metal and resin diamond tools. It includes 5 panels for QC Metals and 8 panels for 3″ pucks.

MOHS PICK SET

This simple scratch tester helps you determine the hardness of your floor and pick the right tools. This is important for preventing tools from glazing, as well as for achieving optimal cutting speed and longer tool life.

Mohs Scale 2-3 – YELLOW BOND for soft concrete
Mohs Scale 3-5 – GRAY BOND for medium concrete
Mohs Scale 5-7 – RED BOND for hard concrete
Mohs Scale 7-8 – GOLD BOND for extra hard concrete
Mohs Scale 8-9 – WHITE BOND for super hard concrete or thew new BLACK BOND Segments
